High commercial output: 550~570W modules ideal for office buildings, factories, and commercial rooftops.
Stable energy generation: Ensures reliable performance for distributed and grid-connected systems.
Durable in extreme conditions: Rated for -40°C to +85°C operation.
International certification: CE and ISO approved for global installations.
Self-cleaning surface: Maintains high energy yield by minimizing dust and debris accumulation.
Curved 128° R-angle structure: Reduces pressure from wind and snow, improving mechanical stability.
Strong frame adhesion: Increases module lifespan and resistance to environmental stress.
Anti-reflective coated glass: Enhances sunlight absorption even under low-irradiance conditions.
The 550~570W N-TOPCON / PERC Monocrystalline Solar Panel is engineered for commercial-scale solar installations, delivering high-efficiency power output with consistent performance. Utilizing N-TOPCon and PERC monocrystalline technology, it ensures long-term reliability in diverse environmental conditions, making it suitable for grid-connected commercial systems.
|
MECHANICAL SPECIFICATION |
OPERATING PARAMETERS |
||||
|
Cable(Including connector) |
4.0mm²,300/400mm in length, length can be customized |
Maximum system voltage |
1500V DC |
||
|
Operating Temperature |
-40~+85℃ |
||||
|
No.of Cells |
144(6×24) |
Maximum series fuse rating |
20A |
||
|
Glass |
3.2mm High Transmission, Antireflection Coating |
Snow load, frontside/Wind load, backside |
5400Pa/2400Pa |
||
|
Junction box |
IP68,3 Bypass Diodes |
Nominal operating cell temperature |
42℃±2℃ |
||
|
Connector |
MC4 Compatible |
Application level |
Class A |
||
|
STC--Electrical Characteristics |
|||||
|
Module Type |
DHT-M60X10/FS |
||||
|
Maximum Power(Pmax) |
550W |
555W |
560W |
565W |
570W |
|
Open-circuit Voltage (Voc) |
49.62V |
49.72V |
49.82V |
49.93V |
50.04V |
|
Maximum Power Voltage (Vmp) |
40.90V |
40.99V |
41.09V |
41.21V |
41.34V |
|
Short-circuit Current(lsc) |
14.03A |
14.12A |
14.21A |
14.3A |
14.39A |
|
Maximum Power Current(Imp) |
13.45A |
13.54A |
13.63A |
13.71A |
13.79A |
|
Module Efficiency(%) |
21.29% |
21.48% |
21.68% |
21.87% |
22.07% |
|
Temperature Coefficient of lsc: 0.05%/℃/Temperature Coefficient of Voc: -0.37%/℃/Temperature Coefficient of Pmax:-0.35%/PC |
|||||
|
Standard Test Environment: Iradiance 1000W/m², Cell temperature 25℃Spectrum AM1.5 |
|||||
|
NOCT--Electrical Characteristics |
|||||
|
Maximum Power(Pmax) |
409W |
413W |
417W |
420W |
424W |
|
Open-circuit Voltage (Voc) |
46.84V |
46.93V |
47.02V |
47.13V |
38.84V |
|
Maximum Power Voltage (Vmp) |
38.42V |
38.59V |
38.69V |
38.74V |
41.05 |
|
Short-circuit Current (lsc) |
11.33A |
11.40A |
11.48A |
11.55A |
11.62A |
|
Maximum Power Current(Imp) |
10.65A |
10.70A |
10.77A |
10.85A |
10.92A |
|
Standard Test Environment: Iradiance 800W/m² Ambient temperature 20℃, Spectrum AM1.5, Wind speed 1m/s |
|||||
